Project Profile

The louver spiral finned tube is used to form a three-dimensional spatial structure through bending and twisting layer structure. Two groups of plane spiral finned tube groups, plane fixed support of tube group, base connecting support and base; The two groups of plane spiral finned tube groups are composed of a multi-layer spatial structure spiral finned tube which is bent and twisted as a whole. The plane spiral finned tube group is composed of a serpentine structure in the same plane and a multi-layer spatial structure spiral finned tube which is bent as a whole. The torsion included angle between the plane spiral finned tube groups is 10 ° - 180 °, and a three-dimensional spatial structure is formed through the torsion layer structure between the groups.

Intellectual property

•

  Rotary wing products were filed for 11 patents, 4 have been authorized to invent, 7 utility models. 2 of the invention patents apply for PCT patents. 1 has passed the international stage, which has be

•

  Shutter-type three-dimensional efficient spiral heat exchanger has passed the scientific and technological achievements appraisal of Henan Science and Technology Department

•

  Shutter-type three-dimensional efficient spiral heat exchanger access to the recognition of Henan Science and Technology Department and was awarded the third prize of scientific and technological prog
